Xenio i1000

Iris Recognition Employee Time Clock
Designed for today’s workforce the ideal all purpose time clock.
biometric iris time clocks


The XENIO-i1000 is the most advanced iris recognition terminal designed for today’s connected cloud and IoT “internet of things” world. This robust, contactless, and hygienic solution verifies a user’s identity based on the characteristics of their iris. While many mistake it for retinal scanning, iris recognition simply takes a picture of the iris; this picture is used solely for authentication. The user stands in front the iris terminal and in less than a second their identity is verified. Iris recognition is the most accurate form of identifying an individual in high traffic areas. Leave fingerprint privacy and performance concerns behind with the Xenio i1000.


Automatic Face Detection & Iris Capture (1)

Automatic Face Detection & Iris Capture

The proprietary face-finding function makes this a touch-free system. The iris camera activates when a user approaches and automatically tilts to the correct angle for each user, quickly adjusting to the user’s height.


Innovative face display —like a smart phone “Selfie”— allows for easy and lightning fast authentication.

Mifare Smart Card Reader

The Xenio i-1000 has a built-in Smart Mifare Card Reader, adding a second layer of security. Compatible with Mifare 1K, 4K, Classic.

Real Time Communication

Designed with today’s connected world in mind (IoT “internet of things”, m2m “machine to machine”). Our communication technology leverages seamless real time data transfer from our devices to third party systems and vice versa.
Real Time Communication
Xenio - i1000 Specs


Height:166mm /6.5in Width:166mm / 6.5in
Deep:43mm / 1.7in


5 inches
Capacitive touch
Color LCD


Iris template capacity: 10,000 1:N (50,000 optional)
Iris verification speed: Under 1 sec
Iris image output: Meets new ISO 19794-6 2011 standard
Iris image pixel res: 640 x 480 pixels, 8 bit depth.
Supports multiple formats.
Eye safety Standard: IEC 62471
Iris positioning alerts:
Subject too far away
Red: Subject is too close
Green: Subject within capture range

Communication Interface

10/100 Ethernet
1 Programmable Universal Relay
RS485 (COM)
RS232 (COM)
Wiegand Output/Input
2 TTL Inputs

Procesor and Memory

Quad Core ARMA9 Cortex@1.5Ghz
User Capacity: 10,000
Record Capacity: 1 Million

Smart card Technology

Frequency: 13.56 Mhz
Technology: Mifare 1k, 4k Classic


Input 110 – 240VAC @ 3A
Adapter Included
